Refuse Trailers
ROLL OFF TRAILER
SUMMARY
The Universal Handling Equipment provides the most reliable roll off trailer in the industry. Its high strength engineered materials, hydraulic controls and Universal's rigorous quality testing eliminates potential down time for the trailer. Its product features include:
  • Five available models to choose from: pup trailers, single & tandem dolly trailers, live pup trailers, live dolly roll off trailers, and semi trailers
  • Trailer configurations available for single and two box containers
  • Fabricated main frame rails
  • Roll off rails to suit any type of roll off container
  • Double race turn table for full dolly trailers
  • ABS secondary filter adds 100,000 miles to ABS warranty
SPECIFICATION & DATA
Documents
MOBILE TRAILERS BROCHURE.PDF
Body Specifications (varies by model)
Typical Trailer Main Rails Fabricated I Beam with 100 Q steel
Hydraulics (varies by model)
Control valve Sectional High Flow Air Actuated
Hoses SAE 100R12 with abrasion resistant cover
Running Gear (varies by model)
Heavy wall tapered spindle, 5" round axles
11R 22.5 Tires
22.5 x 8.25 Disc Wheels - 10 Stud Hub Piloted
Haldex ABS system - 2S1M System Standard
Q-Type Brake Shoes, Achorlock 30-30 Spring Brakes
Spring, Rubber Block & Air Ride Suspension - Hendrickson or Reyco
25,000/30,000 lb Capacity per Axle
Holland Mark V, 180,000 lb Capacity - 2 Speed Crank
Electrical (varies by model)
All wiring sealed & run through tubing
Front Wall 7-Way ATA Receptable c/w Air Connections

Specification data on this website is provided for informational purposes and is not guaranteed to be accurate, may contain errors, and is subject to change without notice.

OPTIONS
Fenders
  • Steel
  • Plastic
  • Aluminum
Hydraulic
  • Stinger Tails
Mechanical
  • Aluminum Rims
  • Spring, Air or Rubber Block Suspensions
  • One or Two Box Configurations
  • Tie Down Chains
  • Variety of Tarp Systems Available
  • ICC Underride Bumpers
  • Inside/Outside Rails
  • Inside/Outside Rollers
Models
  • Pup Trailers
  • Single & Tandem Dolly Trailers
  • Live Pup Trailers
  • Live Dolly Roll Off Trailers
Tool Box
  • Steel
  • Plastic
  • Aluminum
