ROLL OFF TRAILER -
LUGGER TRAILER
SUMMARY
Universal lugger trailers provide precision performance through superior engineering, and deliver greater payload capacities with operational ease. They also come in various designs and capacities, all engineered for exceptionally long service life. Its product features include:
- Two available models to choose from: pup trailers, single & tandem dolly trailers
- Two available models to choose from: pup trailers, single & tandem dolly trailers
- Fabricated main frame rails
- Solid steel deck to accomodate all lugger containers
- Double race turn table for full dolly trailers
- ABS secondary filter adds 100,000 miles to ABS warranty
- Container tie downs
SPECIFICATION & DATA
Body Specifications (varies by model)
| Trailer Main Rails | Fabricated I Beam with 100 Q steel |
Hydraulics (varies by model)
| Control valve | Sectional High Flow Air Actuated |
| Hoses | SAE 100R12 with abrasion resistant cover |
Running Gear (varies by model)
| Heavy wall tapered spindle, 5" round axles | |
| 11R 22.5 Tires | |
| 22.5 x 8.25 Disc Wheels - 10 Stud Hub Piloted | |
| Haldex ABS system - 2S1M System Standard | |
| Q-Type Brake Shoes, Achorlock 30-30 Spring Brakes | |
| Spring, Rubber Block & Air Ride Suspension - Hendrickson or Reyco | |
| 25,000/30,000 lb Capacity per Axle | |
| Holland Mark V, 180,000 lb Capacity - 2 Speed Crank |
Electrical (varies by model)
| All wiring sealed & run through tubing | |
| Front Wall 7-Way ATA Receptable c/w Air Connections |
Paint
| Urethane Black |
Specification data on this website is provided for informational purposes and is not guaranteed to be accurate, may contain errors, and is subject to change without notice.
OPTIONS
Fenders
- Steel
- Plastic
- Aluminum
Mechanical
- Spring, Air or Rubber Block Suspensions
- One, Two or Three Box Configurations
- Tie Down Chains
- ICC Underride Bumpers
- Headache Rack
- Variety of tarp Systems Available
- Aluminum Rims
Models
- Pup Trailers
- Single & Tandem Dolly Trailers
- Single, Two & Three Box Lugger Trailers
Paint
- Urethane Black
Tool Box
- Steel
- Plastic
- Aluminum
