Hooklift Trucks
AMPLIROLL AMP 150 SERIES - 40,000 LBS
SUMMARY
40,000 lbs hoist designed to handle containers between 12' and 22' of length. Universal Handling Equipment is a certified Ampliroll Hooklift dealer. Proud to offer customers sturdy, long lasting hooklift equipment to fit a wide range of projects.
SPECIFICATION & DATA
Documents
40000LBS BROCHURE.PDF
Body Construction
ASTM A 572 Alloy Steel Jib
ASTM A 572 Alloy Steel Central Arm
ASTM A 572 Alloy Steel Tilting Frame
Hook Height
Standard 61 3/4"
Optional 54"
Hydraulic
Pump Axial piston, 5,700 psi, 20 GPM @ 1,200 RPM, Standard - DIN Shaft or Optional SAE 7/8th Shaft
Controls Low pressure hydraulic, cable or air in cab
Reservoir 20 gallons
Filter 10 micron, return line with replaceable cartridge
Max Operating Pressure 4,800 psi
Hoses, Tubes and Fittings all JIC/SAE specifications
Painting
Standard Black
Custom Custom Colours available upon request

Specification data on this website is provided for informational purposes and is not guaranteed to be accurate, may contain errors, and is subject to change without notice.

OPTIONS
Body Options
  • Additional LED Work Lights
  • Back-Up cameras
  • Pintle plate and hook
  • Variety of tarp systems available
Fenders
  • Plastic
  • Aluminum
  • Steel
Hook Height
  • Optional adjustable hook height
Painting
  • Custom colours available upon request
Toolboxes
  • Plastic
  • Aluminum
  • Steel
